Multischalter 13-8 EMP

Technische Daten EMP 13-8

Frequency Range

LNB-Inputs

950-2150 MHz

Terr. Input

40-862 MHz

Outputs

40-2150 MHz

Control

DiSEqC commands 1.0, 2.0

Insertion Gain

950-2150 MHz

0 dB avg

40-862 MHz

2 dB avg

SAT Inputs Isolation

Between V/H Polarisations

20 dB min

Between Low and High Bands

20 dB min

Between Sat Systems A and B

25 dB min

Maximum Input Level*

Sat.

90 dBµV avg

Terr.

90 dBµV avg

Maximum Output Level*

Sat.

90 dBµV avg

Terr.

88 dBµV avg

Power Consumption

From each receiver

75 mA (18V)

From an internal power supply

6.5 W + LNB

Dimensions (w,d,h [cm])

47 x 15.2 x 8.7 cm (power cord length 130 cm)

Temperature range

-25 °C - +60 °C
