Multischalter 5-8 EMP Centauri

Technische Daten EMP 5-8 MS5/8EIA-4

Frequenzbereich

LNB-Inputs

950-2150 MHz

Terr. Input

40-862 MHz

Outputs

40-2150 MHz

Control

13/18 V + 0/22 kHz

Verlust

SAT

3 dB avg

TERR.

3 dB avg

SAT Enkopplung

Between V/H Polarisations

20 dB min

Between Low and High Bands

25 dB min

Maximum Input Level*

Sat.

90 dBµV avg

Terr.

93 dBµV avg

Maximum Output Level*

Sat.

87 dBµV avg

Terr.

90 dBµV avg

Power Consumption

From each receiver

40 mA (18V)

From an internal power supply

6 W + LNB

Dimensions (w,d,h [cm])

26,5 x 15.2 x 8.7 cm (power cord length 130 cm)

Temperature range

-25 °C - +60 °C
